2-9
ASUS RS400-E8-PS2, RS400-E8-PS2-F
Retention tab
Load lever
edge of load plate
12. Pushthereghtloadleverdown(K)ensuringthattheedgeoftheloadplateisxedand
tuckedsecurelyunderthelever(L),theninsert the right load lever under the retention
tab(M).
• Ensure that the Thermal Interface
Materialisspreadinaneventhin
layer.
• Some heatsinks come with
pre-applied Thermal Interface
Material.Ifso,skipthisstep.
13. ApplysomeThermalInterfaceMaterial
totheexposedareaoftheCPUthatthe
heatsink will be in contact with.
TheThermalInterfaceMaterialistoxicandinedible.DONOTeatit.Ifitgetsintoyoureyes
ortouchesyourskin,washitoffimmediately,andseekprofessionalmedicalhelp.
