Asus RS400-E8-PS2 - Internal Features

Chapter 1: Product introduction
1-8
1.6 Internal features
The barebone server includes the basic components as shown.
1. Power supply and power fan
2. PCI Express slot (with Riser Card installed by factory default)
3. ASUS Z10PR-D16 Server Board
4. System fans (40mm x 28mm)
5. 2.5-inch SSD Bays 1 (upper) — Connect to SATA1 port
6. 2.5-inch SSD Bays 2 (lower) —Connect to SATA2 port
7. Asset Tag
8. Front I/O panel
9. Air duct (installed by factory default)
3
6
7
8
RS400-E8-PS2
1
2
4
4
4
4
4
4
5
Riser Card
9
