Asus RS400-E8-PS2 - ATX Power Connectors (24-Pin EATXPWR1, 8-Pin EATX12 V1, 8-Pin EATX12 V2)

Chapter 4: Motherboard information
4-12
9. ATXpowerconnectors(24-pinEATXPWR1,8-pinEATX12V1,8-pin EATX12V2)
TheseconnectorsarefortheATXpowersupplyplugs.Thepowersupplyplugsare
designedtottheseconnectorsinonlyoneorientation.Findtheproperorientationand
pushdownrmlyuntiltheconnectorscompletelyt.
• DONOTforgettoconnectthe24-pinandthe8-pinpowerplugs;otherwise,thesystem
willnotbootup.
• Useofapowersupplyunit(PSU)withahigherpoweroutputisrecommendedwhen
conguringasystemwithmorepower-consumingdevices.Thesystemmaybecome
unstableormaynotbootupifthepowerisinadequate.
• ThismotherboardsupportsATX2.0PSUorlaterversion.
• EnsurethatyourPSUcanprovideatleasttheminimumpowerrequiredbyyour
system.
