Chapter 2: Hardware setup
2-12
DualCPUconguration
DIMM (CPU1) DIMM (CPU2)
A2 A1 B2 B1 C2 C1 D2 D1
E2 E1 F2 F1 G2 G1 H2 H1
2 DIMMs
P P
4 DIMMs
P P P P
8 DIMMs
P P P P P P P P
12 DIMMs
P P P P P P P P P P P P
16 DIMMs
P P P P P P P P P P P P P P P P
SingleCPUconguration(mustbeinstalledonCPU1)
DIMM
A2 A1 B2 B1 C2 C1 D2 D1
1 DIMM
P
1 DIMM
P
2 DIMMs
P P
4 DIMMs
P P P P
8 DIMMs
P P P P P P P P
DualCPUconguration
YoucanrefertothefollowingrecommendedmemorypopulationforadualCPUconguration.
SingleCPUconguration
YoucanrefertothefollowingrecommendedmemorypopulationforasingleCPUconguration.
