Asus SABERTOOTH 990FX R3.0 User Manual

4-12
Chapter 4: Software Support
Chapter 4
4.4.2 USB 3.1 Boost
USB 3.1 Boost technology supports UASP (USB Attached SCSI Protocol) that automatically
speeds up the transfer rates of your USB storage devices.
Launching USB 3.1 Boost
To launch USB 3.1 Boost, cclick on the left of the AI Suite 3 main menu, then select USB
3.1 Boost.
Using the USB 3.1 Boost
• USB 3.1 Boost automatically detects the USB 3.1/3.0 devices that support UASP.
• The data transfer speed varies with USB devices. For a higher data transfer
performance, use a USB 3.1 device.
Click or tap to select a USB device
Click or tap to enable the USB
device’s normal data transfer rate
Click or tap to enable UASP or
Turbo Mode for a faster data
transfer rate
Ensure to connect your USB 3.1/3.0 device to the USB 3.1/3.0 ports that support USB 3.1
Boost. Refer to section 2.3.1 Rear I/O connection of your user guide for more details.

Asus SABERTOOTH 990FX R3.0 Specifications

General

Chipset	AMD 990FX/SB950
CPU Support	AMD AM3+ FX/Phenom II/Athlon II/Sempron 100 Series Processors
CPU Socket Type	AM3+
Storage	6 x SATA 6Gb/s
SATA RAID	RAID 0, 1, 5, 10
Audio	Realtek ALC1150 8-Channel High Definition Audio CODEC
LAN	Intel I211-AT, 1 x Gigabit LAN Controller(s)
Form Factor	ATX
Dimensions	12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
Memory Support	4 x DIMM, Max. 32GB, DDR3 1866/1600/1333/1066 MHz, ECC, Non-ECC, Un-buffered Memory
Expansion Slots	1 x PCIe 2.0 x1 1 x PCI
USB Ports	12 x USB 2.0 (6 at back panel, 6 at mid-board)
Power Pin	24-pin ATX Power Connector, 8-pin ATX 12V Power Connector
Multi-GPU Support	Supports NVIDIA Quad-GPU SLI and AMD Quad-GPU CrossFireX Technology
