Asus SABERTOOTH 990FX R3.0 - Layout Contents

ASUS SABERTOOTH 990FX R3.0
1-3
Chapter 1
Layout contents
Connectors/Jumpers/Buttons and switches/Slots Page
1. CPUandchassisfanconnectors(4-pinCPU_FAN,4-pinCPU_OPT,4-pin
CHA_FAN1-3,4-pinW_PUMP)
1-17
2. ATXpowerconnectors(24-pinEATXPWR,8-pinEATX12V) 1-19
3. AM3+CPUsocket 1-4
4. DDR3DIMMslots 1-5
5. MemOK!button 1-10
6. USB3.0connector(20-1pinUSB3_E56,USB3_E78) 1-14
7. AMD
®
SerialATA6.0Gb/sconnectors(7-pinSATA6G_1-5) 1-13
8. M.2socket3 1-16
9. ClearRTCRAM(2-pinCLRTC) 1-11
10. Systempanelconnector(20-8pinPANEL) 1-20
11. DirectConnector(2-pinDRCT) 1-21
12. USB2.0connectors(10-1pinUSB1314,USB1112) 1-15
13. TPMconnector(14-1pinTPM) 1-21
14. USBBIOSFlashbackbutton 2-21
15. Power-onbutton 1-9
16. Serialportconnector(10-1pinCOM1) 1-16
17. Frontpanelaudioconnector(10-1pinAAFP) 1-18
18. Digitalaudioconnector(4-1pinSPDIF_OUT) 1-14
