Neverconnecta1394cabletotheUSBconnectors.Doingsowilldamagethe
motherboard!
YoucanconnectthefrontpanelUSBcabletotheASUSQ-Connectorrst,andtheninstall
theQ-Connector(USB)totheUSBconnectoronboardifyourchassissupportsfrontpanel
USBports.
TheUSB2.0moduleispurchasedseparately.
4. USB 2.0 connectors (10-1 pin USB1314, USB1112)
TheseconnectorsareforUSB2.0ports.ConnecttheUSBmodulecabletoanyof
theseconnectors,theninstallthemoduletoaslotopeningatthebackofthesystem
chassis.TheseUSBconnectorscomplywithUSB2.0specicationthatsupportsupto
48MBpsconnectionspeed.
