ASUS SABERTOOTH 990FX R3.0
3-27
Chapter 3
CPU Fan Profile [Standard]
This item allows you to set the appropriate performance level of the CPU fan.
[Standard] Sets to [Standard] to make the CPU fan automatically adjust depending on
the CPU temperature.
[Silent] Sets to [Silent] to minimize the fan speed for quiet CPU fan operation.
[Turbo] Sets to [Turbo] to achieve maximum CPU fan speed.
[Manual] Sets to [Manual] to assign detailed fan speed control parameters.
The following items appear only when you set CPU Fan Prole to [Manual].
CPU Upper Temperature [70]
Use the <+> and <-> keys to adjust the upper limit of the CPU temperature. The values
range from 20°C to 75°C. The CPU fan will operate at the maximum duty cycle when
the temperature is higher than the limit.
CPU Lower Temperature [20]
Use the <+> or <-> keys to adjust the lower limit of the CPU temperature. The values
range from 20 to 75. The CPU fan will operate at the minimum duty cycle when the
temperature is lower than the limit.
CPU Fan Max. Duty Cycle(%) [100]
Use the <+> and <-> keys to adjust the maximum CPU fan duty cycle. The values
range from 20% to 100%. When the CPU temperature reaches the upper limit, the
CPU fan will operate at the maximum duty cycle.
CPU Fan Min. Duty Cycle(%) [30]
Use the <+> and <-> keys to adjust the minimum CPU fan duty cycle. The values
range from 0% to 100%. When the CPU temperature is lower than the lower limit, the
CPU fan will operate at the minimum duty cycle.
Chassis 1-3 Q-Fan Control [Disabled]
[Disabled] Disables the Chassis Q-Fan control feature.
[Enabled] Enables the Chassis Q-Fan control feature.
The following items appear only when you set Chassis Q-Fan Control to [Enabled].
Chassis Fan 1-3 Speed Low Limit [600 RPM]
This item allows you to disable or set the chassis fan warning speed.
Conguration options: [Ignore] [100 RPM] [200 RPM] [300 RPM] [400 RPM] [500 RPM] [600
RPM]
