ASUS SABERTOOTH 990FX R3.0
4-7
Chapter 4
VGA - Smart Mode
Manually adjust the acceleration and deceleration time of the graphic card’s fans.
Click the sliders to
adjust the settings
Displays the graph of
the thermal settings
Click to load a
saved profile
Click to save a new
profile
Click to undo
changes
Click to apply
changes
VGA
Allows you to congure the thermal settings of an installed ASUS graphics card.
VGA - Auto Mode
The system loads the optimal values for the graphic card’s thermal settings.
The VGA tab on Thermal Radar 2 appears only when you install an optional ASUS
graphics card into your system.
The VGA feature of Thermal Radar 2 supports ASUS NVidia 700/900 Series and
AMD R7/R9 Series graphics card only.
Click to load a
saved profile
Click to save
a new profile
