Basic Trouble Tests
C.
Trouble with Indicator Lights, Speaker, or Ringing
Step 1.
Hold the
T/P
switch on the left side of the voice terminal in the
T
(test)
position.
IF
THEN
All red and green lights flash
The voice terminal operation
alternately and a tone sounds con-
appears to be normal. Since the
tinuously,
test is inconclusive, go on to the
“General Tests.”
The red and green lights appear
Go on to the “General Tests” sec-
dim,
tion to see if you need an auxiliary
power unit.
There is any other pattern of
The trouble is caused by either the
lights and tone; for example, all
voice terminal, control unit, expan-
red and green lights flash alter-
sion module, or cord/cable connec-
nately but the tone does not sound
tions between them.
at all or the tone does not sound
continuously. Another example is
Go on to Step 2.
that some red and green lights
flash alternately or the tone
sounds continuously,
Step 2. Unplug the voice terminal on which the trouble appears from its modular
terminal cord and switch it with a working voice terminal (see Figure 4).
The intercom number of the working voice terminal should be five greater
or five less than that of the voice terminal with trouble. (This is done to
make sure your voice terminals are connected to different expansion
modules.) Also, add to your notes the intercom numbers of the voice ter-
minals switched (for example, “voice terminal with trouble-Intercom 10,”
“voice terminal known to be working-Intercom 15”).
Page 15
