Installing the MERLIN Identifier System
Figure 7.
Connecting Administrative Components
Connecting the Administrative
Keyboard and Display
To connect the Administrative Keyboard and Display to the
MERLIN Identifier Control Unit:
1.
2.
Plug the Administrative Keyboard cord to the MERLIN
Identifier Control Unit port labeled “Keyboard.” Use the
supplied adapter cable if your keyboard cord ends with a
5-pin DIN connector.
If no shelf or desk space is available for the Administrative
Keyboard, mount the keyboard wall mounting brackets on
the wall near the MERLIN Identifier Control Unit using the
#6 x 1/2-inch self-tapping screws (supplied) and plastic
wall anchors.
20
STEP 6:
Connecting Administrative Components
To Next Page
