Installing the MERLIN Identifier System
3.
4.
5.
6.
7.
8.
Follow the instructions under “STEP 4” to mount the MERLIN
Identifier Display to be used as the Administrative Display.
Plug one end of the modular cord into the Administration
Display jack labeled “LINE” and the other end into the
MERLIN Identifier Control Unit jack labeled “Admin
Display.”
Slide the Administrative Mode switch to the “Keybd/Display”
position.
Plug the transformer power cord into the MERLIN Identifier
Administration Display port labeled “9V-DC” and the
transformer into an AC power outlet.
The MERLIN Identifier Control Unit power LED should light
and the
ENTER PASSWORD
prompt should display on the
Administrative Display screen.
Switch on the power to the MERLIN Identifier Control Unit.
Install the MERLIN Identifier Control Unit cover by sliding it
into position from the top.
Connecting the Administrative PC
The Administrative PC can be situated in the same room as the
MERLIN Identifier Control Unit or located in another room. If you
want to locate the Administrative PC in another room, you will
need to install a jack near the MERLIN Identifier Control Unit and
another jack near the Administrative PC, and run an inside wire
between the two jacks before using the procedure that follows.
To connect an Administrative PC to the MERLIN Identifier Control
Unit:
1.
labeled “RS232 Admin.”
Connect the RJ45-to-DB9 adapter labeled “Serial Port
Controller” to the MERLIN Identifier Control Unit port
STEP 6:
Connecting Administrative Components
