Installing the MERLIN Identifier System
4.
5.
6.
7.
8.
Do one of the following:
■
■
If the PC is in the same room as the MERLIN Identifier
Control Unit, connect a modular cord with RJ45
plugs directly between the “Printer Port Controller
Serial Port Only” adapter and the “Serial Port PC”
adapter.
If the PC is in a separate room, connect a modular
cord with RJ45 plugs directly between the “Printer
Port Controller Serial Port Only” adapter on the
MERLIN Identifier Control Unit and its designated
wall jack. Then connect a modular cord with RJ45
plugs directly between the “Serial Port PC” adapter
on the PC’s serial port and its designated wall jack.
Reconnect the PC’s power cord and start the PC and the
communications software.
Set up the PC’S communications software using the
parameters as given under “Connecting the Administrative
PC” in “STEP 6.”
Start the communications program capture feature.
Reconnect the MERLIN Identifier Control Unit power cord.
26
STEP 6:
Connecting Administrative Components
