MERLIN MLX Telephone Wiring
Outlet
Position
Jack 1
Numbers
Outlet
Position
Numbers
Jack 2
To MERLIN LEGEND
Station Jack
(Controller End)
or
MLX Set
(Display End)
To MERLIN Identifier
Control Unit
(Controller End)
or
MERLIN Identifier
Display
(Display End)
Installer Wiring
(“Strapping”)
Figure 10.
104A Termination Outlet Strappings to Connect
MERLIN LEGEND MLX Sets to MERLIN Identifier
60
