18
Inp
(Input Menu)
dspl
(Display Menu)
Outp
(Output Menu)
CtrL
(Calibration
Menu)
Alr
(Alarm Menu)
tunE
(Tune Menu)
r-S
(Recipe Menu)
SUPr
(Supervisor
Menu)
CAL
(Calibration
Menu)
typE dEC.P 01.tY 02.ty Pb1 A1.AA dPn9 r.OPt
bias dF1L 01.Ac 02.Ac Pb2 A1.AO
S.S.r.t
SP.ll Unit 01.cY 02.cY dEr A1.dL HLd.b
SP.Hl bLan 01.LL 02.LL OFFS A1.1H tEr.S
1.F1L 01.Hl 02.HL Int A1.SP r.O1
As stated above, to access the Menus, press and hold the Menu Access key for approximately 3
seconds until a menu label appears in the upper display. There are additional menus presented when an
option is selected under the Option menu; however, the options are non-functional unless the appropriate
option board has been installed.
Pressing the Menu Access key indexes from menu to menu. i.e. pressing the Menu Access key
allows you to scroll along the top line of menus which are displayed in the top (red) window.
Pressing the Mode/Enter key indexes through the parameters in a particular menu; these are displayed
in the lower (green) window.
The Raise and Lower
keys are used to modify the visible menu parameter value. The lower window
will alternate between the parameter and the parameter value.
Display Menu Description
InP
Input Used to select sensor-related parameters, such as input type, limits, and scaling.
Available at the CnFG security level.
dSPL
Display
Used to set or change decimal position and display units. Available at the CnFG
security level.
OutP
Output Used to specify output usage, control methods, and alarms. Available at the
CnFG security level.
Ctrl
Control
Used to select parameters associated with the control methods.
USEr security level.
ALr
Alarm
Used to select alarm parameters . Note: This menu is also functional for
controllers not equipped with alarm hardware; however, alarm indication will be
only visual via the A1 and A2 LEDs on the front panel.
Available at the CnFG
security level.
tunE
Tune
Used to set the autotune damping parameter. Available at the USEr security
level.
r-S
Recipe
Used to set ramp and soak parameters.
Available at the USEr security level.
SUPr
Supervisor
Used to set fail-safe and supervisory parameters. Available at the CnFG security
level.
CAL
Calibration
Used to recalibrate input. Available in the FACt security level.
OPtn
Option
(Option) Used to set serial communications parameters. Activated in the FACt
security level; available at the CnFG security level.
SErL
Communications
(Option)
Used to select switch input functions. Activated in the FACt security
level; available at the CnFG security level.
C-dI
Contact/Digital Input
(Option) Used to select switch input functions. Activated in the FACt security
level.
rAS
Remote Analog Setpoint
(Option) Not Currently Available - for future use.
AOut
Auxiliary Output
(Option) Used to set auxiliary output parameters. Activated in the FACt
security level.
