Display Parameter Available Selections
Out.U
Variable
Proc - process variable
St.Pt - Setpoint value
SCL.L
Low Scale Enter in the full scale of the sensor low scale for PV
retransmit
Enter in the full scale of the setpoint low scale for the SV
retransmit
SCL.H
High Scale Enter in the full scale of the sensor high scale for PV
retransmit
Enter in the full scale of the setpoint high scale for the SV
retransmit
FACt
The Setpoint Variable or Process Variable is transmitted to a remote device (chart recorders, indicators, data
recorders, computers, process controllers, etc.) with 1 of 4 different interfaces:
Option 60: 4-20 mA
Option 61: 1-5 V
Option 62: 0-20 mA
Option 63: 0-5 V
The output signal is scalable in the Auxiliary Output Menu. Multiple remote indicators may be driven by the
controller. However, current and voltage outputs cannot be used simultaneously.
For current (mA) options, the remote indicators are connected in series. The sum of the input resistance for
all remote indicators must be less than 400 ohms. For voltage options, the remote indicators are connected
in parallel. The sum of the currents for all remote indicators must be less than 10 mA.
Operation
You will need to enter the Options menu and tell the controller that it has Auxilliary Output card installed and
must select the type of variable for the output and then specify the low and high scale values.
OPtn
CArd
A.Out
A.Out
Out.U
To Next Page
