Atlanta SFERA - 运送与处理已打开包装的机器; Transporting and Handling the Unpacked

3.3 运送与处理已打开包装的机器
从硬纸板外箱取出机器，如图(3.1) 所示。 抬高
机器 A (图 3.2) 到组装区。
使用适当的 堆高机运送 未打 开包装的机 器 。
任何 其他的处 理方 法而 对机器造 成损害，
将使保固的承诺失效。
在任 何情况下 由于 不平 衡， 机 器零件可能
因滑 动造成危 害的 风险 。缓 慢而平稳 的抬
起机器。
正式 操作前小 心确 认没 有任何人 员出现在
危险区(整个机器工作的范围被视为危险区
域)。
抬高机器的程序如下：
小心将牙插插深到(图 3.2)的指标处，机身的正下方
A (Fig. 3.2).
3.3 TRANSPORTING AND HANDLING THE
UNPACkED MACHINE
Remove the machine from the cardboard box as shown
in (Fig. 3.1).
Lift the machine A (Fig. 3.2) and move it to the installation
area.
USE ONLY A FORkLIFT TRUCk OF
ADEQUATE CAPACITY TO LIFT AND
TRANSPORT THE MACHINE. USING
ANY OTHER SYSTEM WILL NULLIFY THE
WARRANTY FOR ANY DAMAGE CAUSED
TO THE MACHINE.
THERISkOFIMPACTINANYCASEREMAINS,
CAUSED BY SUDDEN MOVEMENT DUE TO
UNBALANCING OF THE MACHINE PARTS
IN THE EVENT THAT THE BELTS SAG
OR SLIP. LIFT THE MACHINE SLOWLY
AND SMOOTHLY (WITHOUT j ER k ING OR
IMPULSES).
ALWAYSCHECk,BEFOREANYOPERATION,
THAT THERE ARE NO EXPOSED PERSONS
IN HAZARDOUS ZONES (IN THIS CASE
THE ENTIRE ZONE SURROUNDING THE
PALLETS IS TO BE CONSIDERED AS A
HAZARDOUS ZONE).
To lift the machine, proceed as follows:
Very carefully insert the forks of the lift truck as far as
possible into the guides A (Fig. 3.2) underneath the
machine body.
Net weight: 300 kg
净重： 300 kg
Fig. 3.2
A
30
