Atlanta SFERA - LOADING A ROLL OF FILM

5.4 安装胶膜
这是一个普遍的过程(参见图 5.6)。在手册中胶膜架
介绍章节中有具体穿膜操作说明。
a) 降下胶膜架(1)方便放入胶膜. b)
按下急停按钮(2)确保工作安全。
c) 打开胶膜架拉门 (某些型式胶膜架).
d) 将胶膜(3)放入胶膜架轴心(4)上
e) 将胶膜穿入滚轮间
f) 关闭胶膜架拉门
5.3 LOADING A ROLL OF FILM
This is a general procedure (see fig. 5.6). Carriage-specific
operations are described in the relative roll-holder car-
riage manual.
a) Lower the roll-holder carriage (1) to make it easier to
load the roll;
b) press the emergency button (2) in order to work in
safety;
c) open the carriage door (depending on the carriage
model);
d) push the roll (3) onto the carriage pin (4);
e) unwrap the film and thread it between the rollers;
f) close the carriage door.
3
1
4
2
Fig. 5.6
45
