Atlantic 024306 - Page 11

- 11 -
fi g. 6 - Ohmic sensor values (Hydraulic unit)
fi g. 7 - Ohmic sensor values (Outdoor unit)
-20 -10 0 10 20 30 40 50 60 70 80 90 100 110 120 130
10000
1000
100
10
1
- Compressor.
- Discharge.
- Condensation.
- Expansion valve.
- Evaporator inlet.
- Outdoor
Temperature °C
Ohmic value (kΩ)
-50
1000
10000
43907
2490
338
-25 0 25 50 75 °C
°C
0
2500
5000
7500
10000
12500
15000
17500
20000
22500
25000
27500
30000
32500
0 10203040 5060 708090100
Outside sensor QAC34
Heat Pump return sensor.
Heat Pump fl ow sensor.
Alfea Extensa A.I. R32 / INSTALLATION / 2114 - EN
