Installed options
Installed options are confi gured during commissioning (see page 50).
However, you can modify them by accessing the "Installed Options" menu.
Name of Appliance
- Choose the appliance's power.
Electrical backup
- Choose the electrical backup power.
Boiler connection
- If the electrical backup is set to "No", you can then set the boiler connection to "Yes".
- If a power setting is applied to the electrical backup, the boiler connection setting
remains set to "No" and cannot be changed.
Number of Circuits
- Choose the number of circuits.
Cooling
- If the installation is fi tted with cooling function, choose the zone(s):
None / Area 1 / Area 2 / Area 1 and 2.
Name of Appliance
-- KW
Number of circuits 2
3 KWElectrical back-up
Area 1Cooling
Boiler connection No
Installed options
Complete
Installed options
Hydraulic confi guration Area 1
►
Hydraulic confi guration
▼
Heating / Cooling
- Choose the heating zone to confi gure.
Hydraulic confi guration
Area 1 (Direct circuit)
Area 2 (Mixed circuit)
Hot water
