Atlantic 024306 - HP Confi Guration

- 58 -
►
HP Confi guration
▼
HP
HP confi guration HP
Compressor confi guration
Heating/cooling confi guration
DHW confi guration
1
- "Summer/winter switchover outd.T°" Zone 1: ---, 8°C... 30°C.
"Mini. cooling switchover outd. T°": ---, 8°C... 35°C.
"Mini. time prior to heat./cool.switchover ": ---, 8h... 100h.
2
- "Circuit 2 heating": 0°C... 20°C.
- "Circuit 2 cooling": 0°C... -20°C.
1
HP
Heating/cooling confi guration
Summer/winter switchover
outd.T°
18°C
Mini. cooling switchover
outd. T°
---
Mini. time prior to heat./
cool.switchover
24h
Next
2
HP
Complete
Heating/cooling confi guration
Mixing valve compensation
Area 2
Area 2 heating 0°C
Area 2 cooling 0°C
"Switching diff erential": 0°C... 20°C.
"Heat./cool. alternating time": 10 mins... 600 mins.
(with dynamic radiator, set to 40 mins).
“Max charging time”: 120mins... 180mins.
HP
DHW confi guration
Switching differential
7°C
Heat./cool. alternating
time
90 mins
Max charging time
120 mins
Alfea Extensa A.I. R32 / INSTALLATION / 2114 - EN
"Minimum shutdown time": 3 mins... 20 mins.
"Pump speed": 70%... 100%. (fi g. 5, page 10)
"Post-circulation": 0 secs... 600 secs...
"Power shedding operating": Automatic, When needed.
Released: HP = Start / DHW Backup = Stop / 1
st
HP Backup = Stop /
2
nd
HP Backup = Stop / Boiler = Start.
When needed (Locked): HP = Stop / DHW Backup = Stop /
1
st
HP Backup = Stop / 2
nd
HP Backup = Stop / Boiler = Start.
HP
Compressor confi guration
Minimum shutdown time
8 mins
Post-circulation 5s
Pump speed 100%
Power shedding
operating
Released
