HP confi guration
HP confi guration
HP confi guration
HP confi guration
HP
Tariff input confi guration
Electrical back-up
Attenuation
Connection boiler
"Type of use": Power shedding + Off -peak hours / Smartgrid / EXT control.
"EX1: function activation": 230V / 0V.
"EX2: function activation": 230V / 0V.
“EX3: function activation”: 230V / 0V.
Heat Pump
Tariff input confi guration
EX1: function activation
230V
EX2: function activation
EX3: function activation
0V
230V
Type of use
Power shedding +
Off-peak hours
▼
Electrical back-up
"Authorisation if outd. T° <": ---, -15°C... 10°C.
"Switching setting": 0°Cmin... 500°Cmin.
Confi guration
Back-up
Switching setting
100°C min
Authorisation if outd. T° <
2°C
1
- "Authorisation if outd. T°<" : --- , -15°C... 10°C.
"Switching setting" : 10°C.min... 500°C.min.
2
- "Minimum shutdown time" : ---, 1min... 120min.
"Post-circulation" : 0min... 120min.
"DHW operating" : ECO / Comfort.
1
Confi guration
Connection boiler
Switching setting
Next
100°C.min
Authorisation if outd. T°< 2°C
2
Confi guration
Connection boiler
DHW operating
Complete
ECO
Minimum shutdown time
Post-circulation
30min
20min
“Start time” : 00:00 ... 23:50.
“Stop time” : 00:00 ... 23:50.
“Compressor Limitation” : 1% ... 100%, ---.
“Stoping outd. T°” : -20°C ... 5°C.
Recommended setting :
“Compressor Limitation” : 50%
Heat Pump
Attenuation
Start time
22:00
Stop time 07:00
Compressor Limitation ---
Stoping outd. T° 5°C
Alfea Extensa A.I. R32 / INSTALLATION / 2114 - EN
