Atlantic 024306 - Controller Interface; User Interface

- 44 -
 Controller Interface
►
User Interface
Nr Description
1 Menu button
2 Navigation knob (rotate knob), accept (press knob)
3 Back button
MENU
15:23
12°
19,0°
19.5
ECO
19,0°
21.5
ECO
OFF
2 heating circuit version
+ domestic hot water (DHW)
Zone 1 Zone 2
MENU
15:23
12°
19,0°
21,5
ECO
OFF
1 heating Circuit version
+ domestic hot water (DHW)
1
2
3
7 September 2017 7 September 2017
Alfea Extensa A.I. R32 / INSTALLATION / 2114 - EN
