Atlantic 024306 - Fault Diagnosis; Outside Sensor

- 61 -
Errors history
10: Outside sensor, 32: Flow sensor 2, 33: Flow sensor HP,
44: Return sensor HP, 50: DHW sensor 1, 60: Room sensor 1, 65: Room sensor 2,
83: BSB short-circuit, 127: Legionella temp, 212: Internal comm failure, 369: External,
370: Thermodynamic source, 441: BX31 no function, 442: BX32 no function,
443: BX33 no function, 444: BX34 no function, 516: Heat pump missing.
For more info about errors
" Fault Diagnosis", page 70.
Errors history
Error10/09/2016 441
Error10/09/2016 369
Error09/09/2016 441
Error09/09/2016 369
Error20/08/2016 369
Error20/08/2016 369
Error01/08/2016 441
Error01/08/2016 369
Error14/07/2016 441
Error06/05/2016 441
System status
Temperature control
Energy consumption
See " Temperature control", page 48.
Consumption can be displayed per usage:
- Heating (Zones 1 and 2).
- Cooling.
- Domestic Hot Water (DHW).
- Total (Heating + Cooling + Hot Water).
This information is available for:
- the last 8 days: daily consumption (Tdy = Today, D-1 = yesterday, etc.).
- the last 12 months: monthly consumption (Initial letter of month. e.g. J = January, etc.).
- the last 10 years: annual consumption (last 2 digits. e.g. 16 = 2016).
20kW.h
Daily cons.
Heating
D-7 D-6 D-5 D-4 D-3 D-2 D-1 Tdy
Example for daily consumption of the heating system.
Alfea Extensa A.I. R32 / INSTALLATION / 2114 - EN
