POCKET GUIDE TO POWER FOCUS 6000 SYSTEM POCKET GUIDE TO POWER FOCUS 6000 SYSTEM
6 7
SYSTEM OVERVIEW
The core Power Focus 6000 systems consist of the following parts:
• Power Focus 6000 controller
• Intelligent Application Module (IAM)
• Tensor STR tool
• Tensor STR cable
• Accessories and communication interfaces
In the image below you can see how these different parts fit together as a
system in a typical customer environment.
Power Focus 6000 Controller
Power Focus controllers are recognized around the
globe for their outstanding tightening capabilities. The
platform meets the need to enhance error-proofing,
connectivity and flexibility, and is the first to introduce
software ergonomics to the industry. This won the
Power Focus 6000 the prestigious Red Dot design
award in 2012. Learn more about the functionality
of the software or the hardware connections in the
respective chapter.
Intelligent Application Module (IAM)
The intelligent Application Module (IAM) stores all the
• Tightening results
• Events
• Configuration
• Logs
• Software
Carry all information in the palm of your hand and transfer it easy from one
controller to another. The module is located on the inside of the door to the
controller and is available in three different versions:
• IAM Critical control
• IAM Process control
• IAM Process+ control
For a complete overview of the included functionality please see respective
chapter.
The Atlas Copco Tensor STR tool is a complete tool designed to work with
optimal performance together with the Power Focus 6000 controller.
Tensor STR
This Tensor power tool is a result of years of research and development to
improve productivity and quality without compromising ergonomics. Major
ergonomics improvements have been made possible by using the latest and
greatest technology available.
Tensor STR Cable
Atlas Copco has been producing assembly tool cables
since 1987 and has unrivaled experience in the
field. Flexibility and durability have steadily
improved since the introduction of the
company’s first generation cables,
resulting in today’s optimum
cable performance.
Atlas Copco’s flat-cable
design combines
maximum flexibility
(for access to difficult
applications) with

Atlas Copco POWER FOCUS 6000 Specifications

General

Model	POWER FOCUS 6000
Category	Controller
Connectivity	Ethernet, USB
Supply voltage	100-240 V AC
Frequency	50/60 Hz
Fieldbus protocols	PROFINET, EtherNet/IP
Data storage	Internal memory
Operating temperature	0°C to +45°C
Storage temperature	-20 to 70 °C
Relative humidity	90% (non-condensing)
