157
8025I–AVR–02/09
ATmega48P/88P/168P/328P
(RTC). When AS2 is set, pins TOSC1 and TOSC2 are disconnected from Port C. A crystal can
then be connected between the TOSC1 and TOSC2 pins to serve as an independent clock
source for Timer/Counter2. The Oscillator is optimized for use with a 32.768 kHz crystal.
For Timer/Counter2, the possible prescaled selections are: clk
T2S
/8, clk
T2S
/32, clk
T2S
/64,
clk
T2S
/128, clk
T2S
/256, and clk
T2S
/1024. Additionally, clk
T2S
as well as 0 (stop) may be selected.
Setting the PSRASY bit in GTCCR resets the prescaler. This allows the user to operate with a
predictable prescaler.
