44
8025I–AVR–02/09
ATmega48P/88P/168P/328P
7.11 Register Description
7.11.1 SMCR – Sleep Mode Control Register
The Sleep Mode Control Register contains control bits for power management.
• Bits 7..4 Res: Reserved Bits
These bits are unused bits in the ATmega48P/88P/168P/328P, and will always read as zero.
• Bits 3..1 – SM2..0: Sleep Mode Select Bits 2, 1, and 0
These bits select between the five available sleep modes as shown in Table 7-2.
Note: 1. Standby mode is only recommended for use with external crystals or resonators.
• Bit 0 – SE: Sleep Enable
The SE bit must be written to logic one to make the MCU enter the sleep mode when the SLEEP
instruction is executed. To avoid the MCU entering the sleep mode unless it is the programmer’s
purpose, it is recommended to write the Sleep Enable (SE) bit to one just before the execution of
the SLEEP instruction and to clear it immediately after waking up.
7.11.2 MCUCR – MCU Control Register
• Bit 6 – BODS: BOD Sleep
The BODS bit must be written to logic one in order to turn off BOD during sleep, see Table 7-1
on page 39. Writing to the BODS bit is controlled by a timed sequence and an enable bit,
BODSE in MCUCR. To disable BOD in relevant sleep modes, both BODS and BODSE must first
Bit 76543210
0x33 (0x53) – – – – SM2 SM1 SM0 SE SMCR
Read/Write R R R R R/W R/W R/W R/W
Initial Value 0 0 0 0 0 0 0 0
Table 7-2. Sleep Mode Select
SM2 SM1 SM0 Sleep Mode
000Idle
0 0 1 ADC Noise Reduction
0 1 0 Power-down
0 1 1 Power-save
100Reserved
101Reserved
1 1 0 Standby
(1)
1 1 1 External Standby
(1)
Bit 7 6 5 4 3 2 1 0
0x35 (0x55) – BODS BODSE
PUD – – IVSEL IVCE MCUCR
Read/Write R R/W R/W R/W R R R/W R/W
Initial Value 0 0 0 0 0 0 0 0
