.org 0x3C00
0x3C00 RESET: ldi r16,high(RAMEND); Main program start
0x3C01 out SPH,r16 ; Set Stack Pointer to top of RAM
0x3C02 ldi r16,low(RAMEND)
0x3C03 out SPL,r16
0x3C04 sei ; Enable interrupts
0x3C05 <instr> xxx
When the BOOTRST Fuse is programmed, the Boot section size set to 2K bytes and the IVSEL
bit in the MCUCR Register is set before any interrupts are enabled, the most typical and general
program setup for the Reset and Interrupt Vector Addresses in ATmega328P is:
Address Labels Code Comments
;
.org 0x3C00
0x3C00 jmp RESET ; Reset handler
0x3C02 jmp EXT_INT0 ; IRQ0 Handler
0x3C04 jmp EXT_INT1 ; IRQ1 Handler
... ... ... ;
0x3C32 jmp SPM_RDY ; Store Program Memory Ready Handler
;
0x3C33 RESET: ldi r16,high(RAMEND); Main program start
0x3C34 out SPH,r16 ; Set Stack Pointer to top of RAM
0x3C35 ldi r16,low(RAMEND)
0x3C36 out SPL,r16
0x3C37 sei ; Enable interrupts
0x3C38 <instr> xxx
9.5 Register Description
9.5.1 Moving Interrupts Between Application and Boot Space, ATmega88P, ATmega168P and ATmega328P
The MCU Control Register controls the placement of the Interrupt Vector table.
9.5.2 MCUCR – MCU Control Register
• Bit 1 – IVSEL: Interrupt Vector Select
When the IVSEL bit is cleared (zero), the Interrupt Vectors are placed at the start of the Flash
memory. When this bit is set (one), the Interrupt Vectors are moved to the beginning of the Boot
Loader section of the Flash. The actual address of the start of the Boot Flash Section is deter-
mined by the BOOTSZ Fuses. Refer to the section ”Boot Loader Support – Read-While-Write
Self-Programming, ATmega88P, ATmega168P and ATmega328P” on page 277 for details. To
avoid unintentional changes of Interrupt Vector tables, a special write procedure must be fol-
lowed to change the IVSEL bit:
Bit 76543210
0x35 (0x55)
– BODS BODSE PUD – – IVSEL IVCE MCUCR
Read/Write R R R R/W R R R/W R/W
Initial Value00000000
To Next Page
