318

8025I–AVR–02/09

ATmega48P/88P/168P/328P

Figure 26-3. Maximum Frequency vs. V

CC

, ATmega328P

4 MHz

1.8V 2.7V 4.5V

10 MHz

20 MHz

5.5V

Safe Operating Area
