27.1.12 Current Consumption of Peripheral Units
Figure 27-39. ADC Current vs. V
CC
(AREF = AV
CC
).
Figure 27-40. Analog Comparator Current vs. V
CC
.
ADC CURRENT vs. V
CC
AREF = AV
CC
85 °C
25 °C
-40 °C
0
50
100
150
200
250
300
350
400
1.5 2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(uA)
ANALOG COMPARATOR CURRENT vs. V
CC
85 °C
25 °C
-40 °C
0
10
20
30
40
50
60
70
80
90
100
1.522.533.544.555.5
V
CC
(V)
I
CC
(uA)
