Atmel ATmega48PV

368
8025I–AVR–02/09
ATmega48P/88P/168P/328P
Figure 27-75. Reset Input Threshold Voltage vs. V
CC
(V
IL
, I/O Pin read as ‘0’).
Figure 27-76. Reset Pin Input Hysteresis vs. V
CC
.
RESET INPUT THRESHOLD VOLTAGE vs. V
CC
VIL, IO PIN READ AS '0'
85 °C
25 °C
-40 °C
0
0.5
1
1.5
2
2.5
1.5 2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
Threshold (V)
RESET PIN INPUT HYSTERESIS vs. V
CC
85 °C
25 °C
-40 °C
0
0.1
0.2
0.3
0.4
0.5
0.6
1.5 2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
Input Hysteresis (mV)
