ATmega48P/88P/168P/328P
Figure 27-89. Programming Current vs. V
CC
.
27.2.13 Current Consumption in Reset and Reset Pulsewidth
Figure 27-90. Reset Supply Current vs. Low Frequency (0.1 - 1.0 MHz).
PROGRAMMING CURRENT vs. V
CC
85 °C
25 °C
-40 °C
0
2
4
6
8
10
12
14
16
1.5 2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(mA)
RESET SUPPLY CURRENT vs. LOW FREQUENCY
0.1 - 1.0 MHz
5.5 V
5.0 V
4.5 V
4.0 V
3.3 V
2.7 V
1.8 V
0
0.05
0.1
0.15
0.2
0.25
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
Frequency (MHz)
I
CC
(mA)
