Figure 27-99. Idle Supply Current vs. Frequency (1-20 MHz).
Figure 27-100.Idle Supply Current vs. V
CC
(Internal RC Oscillator, 128 kHz).
IDLE SUPPLY CURRENT vs. FREQUENCY
1 - 20 MHz
5.5 V
5.0 V
4.5 V
0
0.5
1
1.5
2
2.5
3
3.5
4
4.5
5
02468 10 12 14 16 18 20
Frequency (MHz)
I
CC
(mA)
4.0 V
3.3 V
2.7 V
1.8 V
IDLE SUPPLY CURRENT vs. V
CC
INTERNAL RC OSCILLATOR, 128 KHz
85 °C
25 °C
-40 °C
0
0.005
0.01
0.015
0.02
0.025
0.03
0.035
0.04
0.045
0.05
1.5 2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(mA)
