ATmega48P/88P/168P/328P
27.3.5 Power-save Supply Current
Figure 27-105.Power-Save Supply Current vs. V
CC
(Watchdog Timer Disabled and 32 kHz
Crystal Oscillator Running).
27.3.6 Standby Supply Current
Figure 27-106.Standby Supply Current vs. Vcc (Watchdog Timer Disabled).
POWER-SAVE SUPPLY CURRENT vs. V
CC
WATCHDOG TIMER DISABLED and 32 kHz CRYSTAL OSCILLATOR RUNNING
0
0.2
0.4
0.6
0.8
1.0
1.2
1.4
1.6
1.5 2 2.5 33.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(uA)
25 °C
STANDBY SUPPLY CURRENT vs. V
CC
WATCHDOG TIMER DISABLED
6MHz_xtal
6MHz_res
4MHz_xtal
4MHz_res
2MHz_xtal
2MHz_res
1MHz_res
0
0.02
0.04
0.06
0.08
0.1
0.12
0.14
0.16
0.18
0.2
1.5 2 2.5 33.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(mA)
