Figure 27-137.Reset Supply Current vs. Frequency (1 - 20 MHz).
Figure 27-138.Minimum Reset Pulse width vs. V
CC
.
RESET SUPPLY CURRENT vs. FREQUENCY
1 - 20 MHz
5.5 V
5.0 V
4.5 V
0
0.5
1
1.5
2
2.5
3
3.5
4
02468 10 12 14 16 18 20
Frequency (MHz)
I
CC
(mA)
4.0 V
3.3 V
2.7 V
1.8 V
MINIMUM RESET PULSE WIDTH vs. V
CC
85 °C
25 °C
-40 °C
0
200
400
600
800
1000
1200
1400
1600
1800
1.5 2 2.5 33.5 4 4.5 5 5.5
V
CC
(V)
Pulsewidth (ns)
