Atmel ATmega48PV

411
8025I–AVR–02/09
ATmega48P/88P/168P/328P
Figure 27-157.Reset Pull-up Resistor Current vs. Reset Pin Voltage (V
CC
= 2.7 V).
Figure 27-158.Reset Pull-up Resistor Current vs. Reset Pin Voltage (V
CC
= 5 V).
RESET PULL-UP RESISTOR CURRENT vs. RESET PIN VOLTAGE
V
CC
= 2.7V
0
10
20
30
40
50
60
70
0 0.5 1 1.5 2 2.5 3
V
RESET
(V)
I
RESET
(uA)
85 °C
25 °C
-40 °C
RESET PULL-UP RESISTOR CURRENT vs. RESET PIN VOLTAGE
V
CC
= 5V
0
20
40
60
80
100
120
0123 456
V
RESET
(V)
I
RESET
(uA)
85 °C
25 °C
-40 °C
