22. Electrical Characteristics
22.1 Absolute Maximum Ratings*
Operating Temperature.................................. -40°C to +125°C
*NOTICE: Stresses beyond those listed under “Absolute
Maximum Ratings” may cause permanent dam-
age to the device. This is a stress rating only and
functional operation of the device at these or
other conditions beyond those indicated in the
operational sections of this specification is not
implied. Exposure to absolute maximum rating
conditions for extended periods may affect device
reliability.
Storage Temperature ..................................... -65°C to +150°C
Voltage on any Pin except RESET
with respect to Ground ................................-0.5V to V
CC
+0.5V
Voltage on RESET
with respect to Ground......-0.5V to +13.0V
Maximum Operating Voltage ............................................ 6.0V
DC Current per I/O Pin ............................................... 40.0 mA
DC Current
V
CC
and GND Pins................................ 200.0 mA
Table 22-1. DC Characteristics T
A
= -40°C to 125°C, V
CC
= 2.7V to 5.5V (unless otherwise noted)
(1)
.
Symbol Parameter Condition Min.
(2)
Typ. Max.
(3)
Units
V
IL
Input Low Voltage
Except RESET
and XTAL
pins
-0.5 0.3V
CC
V
V
IL1
Input Low Voltage XTAL pin -0.5 0.1V
CC
V
V
IL2
Input Low Voltage RESET pin -0.5 0.1V
CC
V
V
IH
Input High-voltage
Except RESET
and XTAL
pins
0.6V
CC
(3)
V
CC
+0.5 V
V
IH1
Input High-voltage XTAL pin 0.9V
CC
(3)
V
CC
+0.5 V
V
IH2
Input High-voltage RESET pin 0.9V
CC
(3)
V
CC
+0.5 V
V
OL
Output Low Voltage
(4)
(Port B) except PB5
I
OL
= 8 mA, V
CC
= 5V
I
OL
= 5 mA, V
CC
= 3V
0.6
0.5
V
V
V
OH
Output High-voltage
(5)
(Port B) except PB5
I
OH
= -8 mA, V
CC
= 5V
I
OH
= -5 mA, V
CC
= 3V
4.1
2.3
V
V
V
OL1
Output Low Voltage
(4)
PB5
I
OL
= 1 mA 0.6 V
V
OH1
Output High-voltage
(5)
PB5
I
OH
= -200µA, V
CC
= 5V 3.2 V
I
IL
Input Leakage
Current I/O Pin except
RESET
Vcc = 5.5V, pin low
(absolute value)
50 nA
I
IH
Input Leakage
Current I/O Pin except
RESET
Vcc = 5.5V, pin high
(absolute value)
50 nA
R
RST
Reset Pull-up Resistor 30 60 kΩ
R
pu
I/O Pin Pull-up Resistor 20 50 kΩ
