Atmel ATtiny25 User Manual

176
7598H–AVR–07/09
ATtiny25/45/85
23.10 Current Consumption in Reset and Reset Pulse width
Figure 23-41. Reset Supply Current vs. V
CC
(0.1 - 1.0 MHz, Excluding Current through the
Reset Pull-up)
Figure 23-42. Reset Supply Current vs. V
CC
(1 - 24 MHz, Excluding Current through the Reset
Pull-up)
RESET SUPPLY CURRENT vs. V
CC
0.1 - 1.0 MHz, EXCLUDING CURRENT THROUGH THE RESET PULLUP
5.5 V
5.0 V
4.5 V
4.0 V
3.3 V
2.7 V
1.8 V
0
0.02
0.04
0.06
0.08
0.1
0.12
0.14
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
Frequency (MHz)
I
CC
(mA)
RE S E T S UP P LY CURRE NT vs . V
CC
1 - 20 MHz , EXCLUDING CURRENT THROUGH THE RESET PULLUP
5.5 V
5.0 V
4.5 V
4.0 V
3.3 V
2.7 V
1.8 V
0
0.5
1
1.5
2
2.5
0 2 4 6 8 10 12 14 16 18 20
Frequency (MHz)
I
CC
(mA)
