23.7 BOD Thresholds and Analog Comparator Offset
Figure 23-31. BOD Thresholds vs. Temperature (BODLEVEL Is 4.3V)
Figure 23-32. BOD Thresholds vs. Temperature (BODLEVEL Is 2.7V)
BOD THRES HOLDS vs . TEMP ERATURE
BODLEVEL = 4.3V
Ris ing
Fa lling
4
4.05
4.1
4.15
4.2
4.25
4.3
4.35
4.4
-50 -40 -30 -20 -10 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140
Temperature (C)
Threshold (V)
BOD THRES HOLDS vs . TEMP ERATURE
BODLEVEL = 2.7V
Ris ing
Fa lling
2.5
2.55
2.6
2.65
2.7
2.75
2.8
-50 -40 -30 -20 -10 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140
Temperature (C)
Threshold (V)
