Figure 23-5. Active Supply Current vs. V
CC
(Internal RC Oscillator, 8 MHz)
23.2 Idle Supply Current
Figure 23-6. Idle Supply Current vs. Frequency (0.1 - 1.0 MHz)
ACTIVE S UP P LY CURRE NT vs . V
CC
INTERNAL RC OSCILLATOR, 8 MHz
0
1
2
3
4
5
6
7
8
1.52 2.53 3.54 4.55 5.5
V
CC
(V)
I
CC
(mA)
125 ˚C
85 ˚C
25 ˚C
-40 ˚C
IDLE SUPPLY CURRENT vs . LOW FREQUENCY
0.1 - 1.0 MHz
5.5 V
5.0 V
4.5 V
4.0 V
3.3 V
2.7 V
1.8 V
0
0.05
0.1
0.15
0.2
0.25
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
Frequency (MHz)
Idle (mA)
