ATtiny25/45/85
Figure 23-29. Reset Input Threshold Voltage vs. V
CC
(VIL, Reset Pin Read As '0')
Figure 23-30. Reset Input Pin Hysteresis vs. V
CC
RE S E T INP UT THRES HOLD VOLTAG E vs . V
CC
VIL, IO PIN READ AS '0'
0
0.5
1.5
2
2.5
1.52 2.53 3.54 4.55 5.5
V
CC
(V)
Threshold
125 ˚C
85 ˚C
25 ˚C
-40 ˚C
125 ˚C
85 ˚C
25 ˚C
-40 ˚C
RE S E T INP UT THRES HOLD VOLTAG E vs . V
CC
VIH, IO PIN READ AS '1'
0
0.05
0.1
0.15
0.2
0.25
1.52 2.53 3.54 4.55 5.5
V
CC
(V)
Threshold
