Atmel ATtiny25

163
7598H–AVR–07/09
ATtiny25/45/85
Figure 23-15. I/O Pin Pull-Up Resistor Current vs. Input Voltage (V
CC
= 5.0V)
Figure 23-16. Reset Pull-Up Resistor Current vs. Reset Pin Voltage (V
CC
= 1.8V)
I/O P IN P ULL-UP RE S IS TOR CURRE NT vs . INP UT VOLTAG E
Vcc = 5.0V
-40 ˚C
85 ˚C
25 ˚C
125 ˚C
0
20
40
60
80
100
120
140
160
0 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5
V
OP
(V)
I
OP
(uA)
RESET PULL-UP RESISTOR CURRENT vs. RESET PIN VOLTAGE
Vcc = 1.8V
125 ˚C
85 ˚C
25 ˚C
-40 ˚C
0
5
10
15
20
25
30
35
40
0 0.2 0.4 0.6 0.8 1 1.2 1.4 1.6 1.8 2
V
RESET
(V)
I
RES ET
(uA)
