Figure 23-35. Watchdog Oscillator Frequency vs. Temperature
Figure 23-36. Calibrated 8 MHz RC Oscillator Frequency vs. Temperature
WATCHDOG OS CILLATOR FREQUENCY vs . TEMP ERATURE
5.5 V
4.0 V
3.6 V
2.7 V
1.8 V
0.1
0.102
0.104
0.106
0.108
0.11
0.112
0.114
0.116
0.118
-40-30-20-100 102030405060708090100110120
Te mpe ra ture
F
RC
(MHz)
CALIBRATED 8MHz RC OSCILLATOR FREQUENCY vs. TEMPERATURE
5.0 V
3.0 V
7.5
7.6
7.7
7.8
7.9
8
8.1
8.2
8.3
8.4
-40-30-20-100 102030405060708090100110120
Te mpe ra ture
F
RC
(MHz)
