AT90CAN32/64/128
Table 21-4. Input Channel and Gain Selections
MUX4..0
Single Ended
Input
Positive Differential
Input
Negative Differential
Input
Gain
00000 ADC0
N/A
00001 ADC1
00010 ADC2
00011 ADC3
00100 ADC4
00101 ADC5
00110 ADC6
00111 ADC7
01000
N/A
(ADC0 / ADC0 / 10x)
01001 ADC1 ADC0 10x
01010 (ADC0 / ADC0 / 200x)
01011 ADC1 ADC0 200x
01100 (ADC2 / ADC2 / 10x)
01101 ADC3 ADC2 10x
01110 (ADC2 / ADC2 / 200x)
01111 ADC3 ADC2 200x
10000 ADC0 ADC1 1x
10001 (ADC1 / ADC1 / 1x)
10010 ADC2 ADC1 1x
10011 ADC3 ADC1 1x
10100 ADC4 ADC1 1x
10101 ADC5 ADC1 1x
10110 ADC6 ADC1 1x
10111 ADC7 ADC1 1x
11000 ADC0 ADC2 1x
11001 ADC1 ADC2 1x
11010 (ADC2 / ADC2 / 1x)
11011 ADC3 ADC2 1x
11100 ADC4 ADC2 1x
11101 ADC5 ADC2 1x
11110 1.1V (V
Band Gap
)
N/A
11111 0V (GND)
