Atmel AVR AT90CAN32 User Manual

413
7679H–CAN–08/08
AT90CAN32/64/128
32.1 TQFP64
64 PINS THIN QUAD FLAT PACK
SIDE VIEW
A
C
J
L
0
O
to 7
O
TOP VIEW
1
64
E1E
D
e
f
11
O
/ 13
O
0.100 mm
LEAD COPLANARITY
A2
A - - - - 1.20 - - - - 0.047
A2 0.95 1.05 0.037 0.041
C
D
0.09 0.20 0.004 0.008
Min
MM
Max
INCH
16.00 BSC
0.630 BSC
J 0.05 0.15 0.002 0.006
f 0.30 0.45 0.012 0.018
L
e
0.45 0.75 0.018 0.030
0.80 BSC
0.0315 BSC
D1
14.00 BSC
0.551 BSC
E
16.00 BSC
0.630 BSC
E1
14.00 BSC
0.551 BSC
Min Max
DRAWINGS
NOT SCALED
