92
7679H–CAN–08/08
AT90CAN32/64/128
9.4.18 Port F Input Pins Address – PINF
9.4.19 Port G Data Register – PORTG
9.4.20 Port G Data Direction Register – DDRG
9.4.21 Port G Input Pins Address – PING
Bit 76543210
PINF7 PINF6 PINF5 PINF4 PINF3 PINF2 PINF1 PINF0 PINF
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value N/A N/A N/A N/A N/A N/A N/A N/A
Bit 76543210
– – – PORTG4 PORTG3 PORTG2 PORTG1 PORTG0 PORTG
Read/Write R R R R/W R/W R/W R/W R/W
Initial Value 0 0 0 0 0 0 0 0
Bit 76543210
– – – DDG4 DDG3 DDG2 DDG1 DDG0 DDRG
Read/Write R R R R/W R/W R/W R/W R/W
Initial Value00000000
Bit 76543210
– – – PING4 PING3 PING2 PING1 PING0 PING
Read/Write R R R R/W R/W R/W R/W R/W
Initial Value 0 0 0 N/A N/A N/A N/A N/A
