Operation
4.9.3 Connecting the hose
15
16
17
15
15
Suction hose
16
Connection for suction hose
17
Vacuum hose
The suction hose is used to suck up the
secretion.
4.10 Operating the Receptal
®
4.10.1 Support for the Receptal
®
secretion canister
• Insert the thread of the support from above
into the borehole at the bottom side of the
device.
• Screw it together with the supplied screw
nut.
4.10.2 Assembling the Receptal
®
secretion canister system
Receptal
®
liner
Receptal
®
outer canister
Insert the Receptal
®
liner into the Receptal
®
outer
canister.
& Close the canister tightly on all sides. Check
again to ensure that the seal is airtight, other-
wise the system will be unable to generate a
vacuum.
• Insert the vacuum hose.
• Connect the Receptal
®
liner and device to the
vacuum hose.
• Connect the suction hose to the Receptal
®
liner.
& Alwaysuselinerswithbuilt-inbacteriallters.
