Technical data
9.0 Technical data
9.1 ATMOS C 161 Aspirator, ATMOS C 261 Aspirator
Voltage 230V~±10%;50/60Hz
Current consumption ATMOSC161Aspirator:max.0.85A
ATMOSC261Aspirator:max.0.46A
Power consumption ATMOSC161Aspirator:max.170VA
ATMOSC261Aspirator:max.105VA
Heat output Approx.100J/s
Fuses T 1.25 A/H
Suction capacity ATMOSC161Aspirator:16±2l/min
ATMOSC261Aspirator:26±2l/min
Max. vacuum at MSL -80kPa(-800mbar;-600mmHg)*,or
80% of daily air pressure
Vacuum adjustment Innitelyvariablevacuumregulator
(mechanical regulation valve)
Vacuum display Vacuum gauge (precision class: 2.5)
-1...0bar(±2.5%ofthenalvalue)
(mmHg, bar, kPA)
Pump Swing piston pump
Available collection canister
Reusable secretion canister:
1 l DDS secretion canister
Interfaces for the use of disposable
systems:
1 l
Sound pressure level 50dB(A)
Operating mode Interval operation
(max. 45 minutes “ON”; min. 60 minutes
“OFF”)
Protective earth conductor resistance -
Earth leakage current -
Touch current N.C.<0.1mA
Patient leakage current -
Ambient conditions:
Transport/storage
• Temperature -30 to +50 °C
• Air humidity without condensation 5 to 90%
• Air pressure 700 to 1060 hPa
Ambient conditions: operation
• Temperature +10 to +35 °C
• Air humidity without condensation 20 to 80 %
• Air pressure 700 to 1060 hPa
