OPERATOR’S AND SAFETY MANUAL
1NO0039UK-00
Zebra 12
11
CHARACTERISTICS
Zebra 12
Max Working height
12.20 m
Max Floor height
10.20 m
Min Floor height
0.37 m
Max outreach (At centre line)
8.10 m
Max working outreach (At centre line)
8.60 m
Structure orientation
360° (Not continuous)
Work platform Rotation
2x 90°
Work platform Dimensions
0.86 x 1.51 m
Max number of persons in the work platform
2
Platform capacity
230 kg
Max admissible wind speed
12.5 m/s (45 km/h)
Max Manual force
400 Newton
Max admissible tilt
4°
Max admissible slope
40%
Overall length (Transport position)
6.05 m
Overall length (Storage position)
4.50 m
Overall width
2.24 m
Overall height (Transport position)
1.99 m
Overall height (Storage position)
2.60 m
Wheelbase
2.00 m
Ground clearance
0.37 m
Oscillating axle travel
0.23 m (14°)
Number of driving wheels
4
Number of steering wheels
2
Tyres (Solid tyres)
21x10-20
Turning radius
Inside
1.72 m
Outside
4.28 m
Travel speed
Transport Position
6 km/h
Platform raised
0.8 km/h
Empty weight
5 200kg
Ground load on one wheel (*)
Effort
3 077 daN
Contact pressure
13.0 kg/cm² (1275 kPa)
(*) : The floor load values indicated may vary depending on the configuration/position of the
machine. An adequate safety margin should be kept with regards to these values.
The weighted acoustic pressure level A on the platform's control station is 78 dB(A).
The weighted acoustic power level emitted by the machine (LWA) is 98 dB (test method
according to European directive 2000/14/CE relating to noise emissions in the environment of
equipment intended to be used outside buildings – Appendix III, Section B, Points 0 and 1).
The total value of the vibrations to which the hand-arm system is exposed does not exceed 2.5m/s².
The average maximum quadratic value weighted by the acceleration frequency to which the whole
body is exposed does not exceed 0.5m/s².
Due to constant improvements made to its products, ATN reserves the right to alter their
specifications and equipment without notice.
