OPERATOR’S AND SAFETY MANUAL
1NO0039UK-00
Zebra 12
35
DANGER
ONLY RUN WITH THE PLATFORM
RAISED ON AN EVEN, FIRM AND
HORIZONTAL SURFACE.
TO AVOID ANY RISK OF TIPPING
OVER, DO NOT DRIVE THE MACHINE
NEAR OBSTACLES OR HOLES OR ON
A SLOPE OR TILT GREATER THAN
THE VALUES INDICATED IN SECTION
2.
4.3. DRIVE STEERING
Drive
1- Select the platform control station and
start the diesel engine.
2- Select the movement speed you want.
Refer to Section 2.3 Crushing and
collision risk..
3- Joystick in neutral position, activate the
enable pedal.
The validation light comes on.
Within 5 seconds, push the joystick
forwards to move forward or pull the
joystick back to reverse. The machine's
travel speed is proportional to the joystick
displacement. If the movement is not
controlled within 5 seconds, the validation light goes off and the pedal must be released
and activated again..
To stop the movement, put the joystick into neutral to reduce the speed then release the
validation pedal.
-NOTE-
When the structure is oriented beyond the rear axle and in particular above the front axle,
the drive movement controls are reversed.
The black and white directional arrows on the pictogram in front of the joystick and those
on the machine's chassis are used to identify the drive direction in relation to the
direction in which the joystick is moved: activate the joystick in the direction indicated
by the arrow which corresponds to the drive direction desired.
Drive direction validation (Option)
Optionally, the machine may be equipped with a drive direction validation mechanism
composed of a light indicator and a push button.
When the structure is oriented beyond the rear axle, the fixed light comes on:
1- Use the black / white arrows on the chassis and on the drive joystick pictogram to identify
the command direction that corresponds to the required drive direction.
2- Activate the validation pedal.
3- Activate the direction validation button.
The light goes off.
4- Within 5 seconds, command the drive movement in the direction selected. If the
movement is not controlled within 5 seconds, the enable pedal must be released and the
validation sequence started again from step 2. Once the machine is running, release the
enable button.
-NOTE-
The light indicator and the enable button are fitted as standard. The function activation /
disabling can be configured in the system: see §8.3.1 - Settings
